Light and ergonomic, the MX 6 is the perfect pedal for all types of mountain biking. With its hollow, steel axle, it is rugged enough for any trail condition. TIME's proprietary ATAC system makes clipping-in super easy, secure, and comfortable. The MX 6 also is self-cleaning, with the ATAC system clearing mud or debris away every time you step in. And by swapping the cleats, you have two release angle options (13º or 17º) along with a self-cleaning design that means you'll always be able to clip in – even in the muddiest of conditions.
FEATURES
- Light and durable trail pedal.
- Easy in or out of cleat.
- Freedom of movement lateral and angular.
- Designed for rugged adventure.
- Cleats included with all pedal purchases.
SPECIFICATIONS
| Axle component | Steel axle |
|---|---|
| Bearings | Steel |
| Body component | Glass-filled |
| Cleats | ATAC cleats |
| Pedal stack height | 18.1mm |
| Angular freedom | 5° to -5° with free cleats, 0° with fixed cleats |
| Contact surface area | n/a |
| Distance pedal spindle / crank arm | 54mm |
| Lateral freedom | 2.5 mm or -2.5 mm |
| Release angle | 10° with ATAC Easy cleats, 13 or 17° with ATAC cleats |
| Tension | n/a |
| Threading | 9/16 - 20 inch |
| Weight (per pedal) | 190g |
| Color (Pedal) | Black/Purple |
| Accessories | ATAC Easy cleats |
| Intended use | Enduro |
| Power Measurement | Not Compatible |
